Fluoroscopic System Resolution Test Tools 07-601
Also used to optimize television system focus, mirror optics and image intensifier settings.

The 07-601 is excellent for resolution checks of fluoroscopic imaging systems. These 7.5" square plastic plates each have a 7 inch square area containing eight groups of copper or brass mesh screening in the following mesh-size ranges: 16 to 60 lines/inch, 30 to 100 lines/inch or 60 to 150 lines/inch. The screens are arranged in an irregular rotation to permit discrete visualization of groups. They can also be used to optimize television system focus as well as mirror optics and image intensifier settings.

Specifications

Dimensions: 7.5 (w) x 7.5 (d) x 0.35 in (t) (19 x 19 x 0.3 cm)

Weight: 0.5 lb (0.225 kg)

Model Name Description
07-601 Fluoroscopic Resolution Tool, 16-60 mesh
07-618 Fluoroscopic Resolution Tool, 60-150 mesh
07-619 Fluoroscopic Resolution Tool, 30-100 mesh
